| Channels | 8 |
| Class | D-Class |
| Power supply voltage / fuse | 6.5 ÷ 15 VDC / 2 x 30A |
| Idling current | 1.5 A |
| Standby Current Draw | 1 mA |
| Consumption @ 14.4 VDC, 2Ω, Max Musical Power | 55 A |
| Remote IN | 4 ÷15 VDC (1 mA) |
| Remote OUT | 6.5 ÷15 VDC (150 mA) |
| ART - Automatic Remote Turn on/ off from OUTPUT BTL speakers | 1.5 VDC |
| Efficiency Rated Power | 82% |
| Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power | 0.05% |
| Bandwidth @ -1,5 dB | 10 Hz ÷ 42 kHz |
| Damping factor @ 1 kHz, 4Ω, 2 VRMS | 100 |
| S/N ratio (A weighted @ 1 V Input) Master Input | 98.5 dBA |
| S/N ratio (A weighted @ 1 V Input) Optical Input | 105 |
| Total Power RMS | 1120 W |
| Minimum load impedance | 8Ch: 2Ω | 4Ch – (Bridge 1/2; 3/4; 5/6; 7/8): 4Ω |
| Output Continuous Power (RMS) @14.4 VDC, 1% THD | • 8 Ch @ 4Ω: 90 W x 8 • 8 Ch @ 2Ω: 140 W x 8 • 4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω: 280 W x 4 |
| Adjustable Crossover | Yes |
